ABB UFC718AE101 HIEE3009936R0101
Advanced Process Control Module
Powering precision in industrial automation and energy management.
⚡ High-speed processing | Multi-protocol support | Rugged reliability
🔍 TECHNICAL DNA
Core Specifications
|
Parameter
|
Specification
|
|---|---|
|
Processor
|
32-bit ARM Cortex-M7 @ 300 MHz
|
|
Memory
|
512 MB Flash
|
|
I/O Channels
|
16 Digital I/O + 8 Analog Inputs
|
|
Analog Resolution
|
24-bit ADC (0–10 V, ±10 V, 4–20 mA)
|
|
Communication
|
PROFINET, EtherNet/IP, Modbus TCP, OPC UA
|
|
Power Supply
|
24 V DC (±15%)
|
|
Operating Temp
|
-40°C to +85°C (-40°F to +185°F)
|
|
Certifications
|
CE, UL, ATEX (Zone 2), IEC 61508 SIL 2
|
🚀 FUNCTIONAL SUPERPOWERS
1. Real-Time Process Control
▸ μs-level response for critical automation tasks (e.g., PID loops, motion control).
▸ Predictive algorithms for energy optimization in HVAC and grid systems.
2. Multi-Layer Connectivity
▸ Edge-to-Cloud Integration: Seamless data flow via OPC UA for IIoT platforms.
▸ Legacy Compatibility: RS-485/Modbus RTU gateway functionality.
3. Industrial Resilience
▸ Galvanic Isolation: 2500 V AC between I/O and logic circuits.
▸ EMC Immunity: Survives surges up to 4 kV (EN 61000-4-5).
4. Scalable Architecture
▸ Hot-swappable I/O cards for field upgrades.
▸ Daisy-chain up to 32 modules via high-speed backplane.
🔧 APPLICATION SPOTLIGHT
Energy & Automation
|
Industry
|
Use Case
|
Key Feature Utilized
|
|---|---|---|
|
Oil & Gas
|
Pipeline pressure monitoring
|
24-bit ADC for leak detection
|
|
Smart Grids
|
Substation load balancing
|
SIL 2 safety compliance
|
|
Manufacturing
|
Robotic cell synchronization
|
PROFINET real-time sync
|
|
Water Treatment
|
Chemical dosing control
|
PID loop optimization
|
📊 COMPETITIVE EDGE
|
Feature
|
Market Average
|
|
|---|---|---|
|
Processing Speed
|
300 MHz Cortex-M7
|
100–200 MHz ARM9
|
|
Isolation
|
2500 V AC
|
1500 V AC
|
|
Protocols
|
4+ (PROFINET, OPC UA, etc.)
|
2–3 protocols
|
|
Temperature Range
|
-40°C to +85°C
|
-25°C to +70°C
|
🛠️ INTEGRATION TOOLKIT
Deployment Made Easy
- ABB Ability™ Suite: Pre-configured templates for rapid deployment.
- Diagnostic Dashboard: Live health monitoring via embedded web server.
- Cybersecurity: TLS 1.3 encryption and role-based access control.
💡 INNOVATION HIGHLIGHTS
- Adaptive Sampling: Auto-adjusts analog input rates (1–1000 Hz) based on noise levels.
- Green Mode: Reduces power consumption by 60% during idle periods.
- AI-Ready: Supports TensorFlow Lite for edge ML inference (e.g., predictive maintenance).
📌 WHY UFC718AE101?
- Extreme Environment Ready: Operates in Arctic cold to desert heat.
- Future-Proof: Firmware updates via ABB Control Manager.
- 24/7 Support: ABB’s global technical network with <2hr response SLA.
🎯 SUMMARY TABLE
|
Attribute
|
UFC718AE101 Advantage
|
|---|---|
|
Speed
|
300 MHz CPU + 24-bit ADC for microsecond control
|
|
Safety
|
SIL 2 certified for critical infrastructure
|
|
Connectivity
|
Bridges OT/IT worlds with OPC UA & IIoT
|
|
Durability
|
Survives harsh industrial environments
|
