ProSoft  PLX82-EIP-PNC Communication gateway

ProSoft PLX82-EIP-PNC: EtherNet/IP to PROFINET Controller Gateway

The ProSoft PLX82-EIP-PNC is a cutting-edge industrial communication gateway designed to bridge the gap between two major industrial automation protocols: EtherNet/IP and PROFINET. This gateway allows controllers based on EtherNet/IP to seamlessly control and communicate with up to 36 PROFINET RT devices, such as field I/O, drives, HMIs, and controllers.

Key Features

1. DIN Rail Mountable Design:
   • The PLX82-EIP-PNC is a stand-alone module that can be easily mounted on a DIN rail, making it ideal for industrial environments where space and organization are critical.
2. Dual Ethernet Ports:
   • The gateway features two Ethernet ports for communication, remote configuration, and diagnostics. This provides redundancy and flexibility in network setup.
3. SD Card Slot:
   • An optional SD card slot is available for storing configuration files. These files can be used for recovery, transferring configurations to another gateway, or general backup purposes.
4. Extensive I/O Connectivity:
   • The gateway supports multiple I/O connections, enabling high-speed control of large PROFINET I/O systems.
5. Isolated Ethernet Ports:
   • The isolated Ethernet ports allow devices using different protocols to be located on different subnets, enhancing network security and flexibility.
6. PROFINET v2 Certification:
   • The PLX82-EIP-PNC is compliant with PROFINET Class A standards and holds PROFINET v2 certification, ensuring interoperability with a wide range of PROFINET devices.
7. Remote Viewing and Diagnostics:
   • The gateway allows for remote viewing and diagnostics of both EtherNet/IP and PROFINET networks, simplifying troubleshooting and maintenance.
8. Embedded EDS AOP:
   • The PLX82-EIP-PNC comes with an embedded EDS AOP, allowing seamless integration with Studio 5000 and RSLogix™ 5000 programming environments.
9. EtherNet/IP I/O Connectivity:
   • With EtherNet/IP I/O connectivity, the gateway eliminates the need for ladder logic programming, simplifying system integration and configuration.

Applications

The ProSoft PLX82-EIP-PNC is ideal for a wide range of industrial automation applications, including:

• Manufacturing Plants: Connecting machines and controllers from different vendors within a manufacturing plant, ensuring seamless communication and control.
• Process Industries: Facilitating communication between process control systems and field devices in industries such as chemicals, pharmaceuticals, and food processing.
• Automation Systems: Integrating automation systems in facilities like warehouses, distribution centers, and automated packaging lines.
• Machine Builders: Enabling machine builders to create flexible and scalable machines that can communicate with both EtherNet/IP and PROFINET devices.

Benefits

• Increased Flexibility: The ability to connect controllers based on EtherNet/IP with PROFINET devices increases system flexibility and interoperability.
• Improved Efficiency: Seamless communication between different protocols reduces downtime and enhances overall system efficiency.
• Cost Savings: By eliminating the need for additional hardware or middleware, the PLX82-EIP-PNC helps reduce overall system costs.
• Scalability: The gateway supports up to 36 PROFINET RT devices, making it suitable for both small and large-scale industrial automation projects.

In summary, the ProSoft PLX82-EIP-PNC is a powerful and versatile communication gateway that enables seamless integration between EtherNet/IP and PROFINET devices in industrial automation applications. Its robust design, extensive features, and ease of use make it an ideal choice for manufacturers and system integrators looking to optimize their industrial automation systems.
