METSO   D201189 (I/O) module

METSO D201189 is a powerful input/output (I/O) module, and the following is a detailed introduction to it:

1、 Product Overview

The METSO D201189 I/O module is designed specifically for industrial automation and process control, featuring high precision, fast response, and stable reliability. It is suitable for various industrial application scenarios, such as production line control, environmental monitoring, etc. It can help users achieve precise control and monitoring of external devices, improve production efficiency and system stability.

2、 Main functions

Input and output functions:

This module has multiple input relays for receiving signals from external devices or sensors. These input relays use optoelectronic isolation technology to ensure the accuracy and stability of signal transmission.

At the same time, the module also has multiple output relays for sending control signals to external devices or actuators. These output relays also use electronic normally open/normally closed contacts to ensure long-term stable operation.

I/O expansion capability:

The METSO D201189 module supports multiple types of I/O expansion modules, and users can choose and add corresponding expansion modules according to their actual needs, thereby increasing the input/output capacity of the module.

By adding expansion modules to the CPU, the maximum configuration can reach 24 discrete inputs, 20 discrete outputs, 8 analog inputs, and 8 analog outputs, meeting the requirements of complex industrial control systems.

Programming and Monitoring:

This module supports the extended programming capability of FL1F SmartRelay, allowing users to implement complex control logic through programming.

The I/O points inside the module can be monitored through programming to ensure the stable operation of the system.

Functional module support:

In addition to a series of industrial standard functional modules, METSO D201189 also supports five new types of functional modules, including astronomical clock, analog filter, maximum and minimum value, average value, and stopwatch, further enhancing its application flexibility.

3、 Product Features

High precision and stability: Advanced technology and materials are used to ensure the high precision and long-term stable operation of the module.

Easy to configure and program: Provides user-friendly programming interfaces and configuration tools to facilitate module configuration and programming for users.

Rich functional modules: supporting multiple functional modules to meet the different needs of users.

Scalability: Supports I/O expansion modules, making it convenient for users to expand according to their actual needs.

4、 Application Fields

The METSO D201189 I/O module is widely used in various industrial automation systems, such as production line control, robot control, environmental monitoring, etc. By integrating with other devices and systems, it can achieve real-time data collection, processing, and transmission, improving production efficiency and product quality.

5、 Operator interface

This module is equipped with an LCD operator interface that can display up to 6 lines of information, with each line containing up to 20 characters. This enables operators to conveniently view the status, parameters, and alarm information of the module. The interface also provides optional white, amber, or red backlight functions, allowing operators to easily distinguish between alarms and alarm states from a distance, improving the convenience and safety of operation.
