C300 controller supports “C series” products
Using the C series 24VDC power supply
8+1 ports (FTE switch)
-Security Selection for L1 Layer Control Environment
-Two ‘Firewalls’ support FTE functionality
-Support redundancy
-Support self diagnosis of power on and operation, with fault indication;
– Uplink information control to ensure communication within the cabinet Zui High Priority;
-Suppression of Broadcasting Information Storm
-The controller is not affected by the traffic of the upper IP network;
● Optional fiber optic interface
-Fiber optic (FO) is used for connecting upper level equipment
-Single mode optical fiber (15 km)
-Multimode fiber (2km)
Analog input card (supports HART protocol) – CC-PAIH01
Analog input card (does not support HART protocol) – CC-PAIX01
Analog output card (supports HART protocol) – CC-PAOH01
Analog output card (does not support HART protocol) – CC-PAOX01
Digital Input Card (24VDC) – CC-PDIL01
Digital input card (supporting SOE) – CC-PDIS01
Digital input card (high voltage) – CC-PDIH01
Digital output card (24VDC) – CC-PDOB01
Digital output card (with relay board) – CC-PDOB01
Multiple low-level analog input card – CC-PAIM01 (mainly used for thermal resistors and thermocouples)
C300 consists of several parts:
-Controller hardware
-Control Execution Environment (CEE)
-Corresponding mechanical and electrical parts? Cabinet power supply? Control network interface
-Fault Tolerant Ethernet (FTE)? 2 Local I/O Link interface
-Running CEE (Control Operating System)
-Support
-PMIO
-C-series I/O
-A-series card type I/O
C300 Controller I/O Link Configuration
-Two links support Zui multiple 64 I/O modules
-Each I/O link is distinguished by different color codes for easy maintenance
-The I/O link address on IOTA is determined by inserting a prefabricated jumper
