GE IS230SNRTH2A

IS230SNRTH2A is a Core Analog Module designed for the Mark VIe system. It is developed by General Electric. A large portion of the analog signal I/O required to operate a gas turbine is provided by the Core Analog (PCAA) module and associated Core Analog (TCAS and TCAT) terminal board. Thermocouple inputs, 4-20 mA current loop I/O, seismic inputs, Linear Variable Differential Transformer (LVDT) excitation and inputs, pulse rate inputs, and servo coil outputs are all provided by PCAA and TCAT.

Functional Description

• The module is suitable for use in simplex, dual, and TMR systems. A single TCAT terminal board distributes signal inputs to one, two, or three PCAA modules.
• An adjacent JGPA board’s shield ground and 24 V field power terminals supplement the terminals on PCAA and TCAT. Module includes a processor board that is shared by all Mark VIe distributed I/O boards, two application I/O boards, and a terminal board.
• The entire module is regarded as the least replaceable unit, and no assistance is provided to diagnose or replace the individual boards that comprise the module.
• The module is powered by a 28 V dc power connector and two RJ45 Ethernet connectors. On the module’s edge, 120 Euro-style box terminals provide field device I/O. Power is supplied to a JGPA board via connector P4. The module is connected to TCAT via two 68-pin cables on connectors P1 and P2.
• PCAA signals are divided into two groups. The TCAT terminal board routes signal inputs that can be fanned from a single input into a single, dual, or TMR PCAA module. Signals dedicated to a single PCAA module are wired to terminals. If the fanned inputs are not required, PCAA can be used without TCAT.
