ABB DSSR122 4899001-NK
Industrial Safety Relay Module
Designed for fail-safe control in high-risk environments.
🚨 KEY FEATURES
|
Feature
|
Detail
|
|---|---|
|
Safety Integrity Level
|
SIL 3 (IEC 61508) / PL e (ISO 13849-1)
|
|
Channels
|
Dual-channel monitoring (2 x Safe Digital Inputs)
|
|
Response Time
|
<15 ms for emergency shutdown
|
|
Voltage Range
|
24 V DC (±10%)
|
|
Contact Configuration
|
2 NO (Normally Open) / 1 NC (Normally Closed) safety outputs
|
|
Operating Temp
|
-25°C to +60°C (-13°F to +140°F)
|
|
Protection Rating
|
IP20 (enclosed panel mounting recommended for harsh environments)
|
⚙️ TECHNICAL SPECIFICATIONS
Inputs
- Safe Digital Inputs: 2 channels, 24 V DC (compatible with NAMUR sensors, emergency stops, and safety interlocks).
- Diagnostic Inputs: Monitors external device health (e.g., contactor feedback).
Outputs
- Safety Outputs:
- 2 NO relays (5 A, 250 V AC)
- 1 NC relay (3 A, 24 V DC)
- Auxiliary Outputs: Non-safety status signals for PLC integration.
Compliance & Certifications
- Standards: IEC 62061, ISO 13849-1, UL 508.
- EMC: Immunity to industrial noise (EN 61000-6-2).
🔧 FUNCTIONAL CAPABILITIES
1. Fail-Safe Operation
- Dual-channel cross-monitoring detects short circuits, wire breaks, and contact welding.
- Auto-reset/Manual reset modes configurable via DIP switches.
2. Diagnostic Intelligence
- LED Status Indicators: Real-time feedback for power, input states, and faults.
- Error Codes: Stored in non-volatile memory for root-cause analysis.
3. Flexible Integration
- Compatible with ABB AC500 PLCs, Safety PLCs, and third-party systems.
- Daisy-chain multiple relays for scalable safety networks.
4. Simplified Wiring
- Spring-clamp terminals for tool-free installation.
- Plug-in design reduces maintenance downtime.
🏭 TYPICAL APPLICATIONS
|
Industry
|
Use Case
|
Safety Function
|
|---|---|---|
|
Robotics
|
Collaborative robot (cobot) emergency stop
|
Halts motion on human intrusion
|
|
Manufacturing
|
Press brake safety interlocks
|
Prevents accidental activation
|
|
Energy
|
Wind turbine access control
|
Locks turbines during maintenance
|
|
Packaging
|
Conveyor jam detection
|
Triggers shutdown to prevent damage
|
🛡️ SAFETY & INNOVATION
Why DSSR122 Stands Out
- Cross-Compatible: Works with ABB’s SafeMove2 for robot safety zones.
- Compact Design: 22.5 mm width saves control panel space.
- Cybersecurity: Tamper-proof firmware with secure boot.
📊 COMPARATIVE ADVANTAGE
|
Parameter
|
Generic Competitor
|
|
|---|---|---|
|
Safety Level
|
SIL 3 / PL e
|
SIL 2 / PL d
|
|
Response Time
|
15 ms
|
30 ms
|
|
Diagnostics
|
Advanced (LED + memory)
|
Basic LED only
|
|
Wiring
|
Tool-free spring clamps
|
Screw terminals
|
🔌 INTEGRATION GUIDE
- Mounting: DIN rail (EN 60715) with 22.5 mm spacing.
- Wiring: Use shielded cables for noise-prone environments.
- Configuration: Set reset mode (auto/manual) via DIP switches.
- Testing: Validate with ABB’s Safety Builder software.
📌 WHY CHOOSE DSSR122?
- Ultra-Fast Response: Minimizes risk in critical scenarios.
- Proactive Maintenance: Diagnostics extend system lifespan.
- Global Support: Backed by ABB’s 24/7 technical service network.
