Bently [ 3500/92 ] 136180-01 - Communication gateway module

Bently [3500/92] 136180-01 is a powerful device, and the following is a detailed introduction to it:
1、 Product Overview
Bently [3500/92] 136180-01, as one of Bently Nevada’s products, is a communication gateway module that also serves as a power controller. It is mainly used for vibration monitoring and mechanical health management systems, providing stable power supply for sensors, monitoring devices, and other key components in the system, ensuring the normal operation of the vibration monitoring system.
2、 Product Features
Power control: This device can provide reliable power support for the vibration monitoring system, ensuring that the system can operate continuously and stably.
Communication gateway: It provides extensive serial (RS232/RS422/RS485) and Ethernet TCP/IP communication capabilities, which can integrate all rack monitoring values and statuses with process control and other automation systems.
Protocol support: Supports Modicon Modbus protocol (via serial communication), Modbus/TCP protocol (serial Modbus variant for TCP/IP Ethernet communication), and Bently Nevada proprietary protocol (for communication with 3500 framework configuration and data acquisition software packages).
High speed data collection: Utilize the high-speed internal network to collect information from other modules in the rack, including current measurement values with timestamps, module status, and current alarm status, with a data collection rate of no more than 1 second.
3、 Application Fields
Bently [3500/92] 136180-01 has a wide range of applications in multiple fields:
Energy industry: It can be applied in fields such as power plants, nuclear power plants, oil and gas facilities, providing power support and data communication for vibration monitoring and mechanical health management systems.
Industrial Automation: This equipment can be used in industrial automation systems to provide power and communication support for automation control equipment and monitoring systems, ensuring stable operation and safe control of the equipment.
Other industrial fields: It is also widely used in industries such as petroleum, chemical, power, and pharmaceuticals to monitor and control the operating status of various industrial equipment and devices.
4、 Product specifications
The specific specifications of Bently [3500/92] 136180-01 include:
Power consumption: The typical value is 5.0 watts (may vary depending on the specific module type).
Dimensions: Height 241mm, Width 24.4mm, Depth 242mm.
Weight: 0.82 kilograms.
Working temperature: -30 to+65 degrees Celsius (storage temperature is -40 to+85 degrees Celsius).
Humidity: 95% (non condensing).
Similar products:
3500/65 145988-02
