Bently | 3500/40M | 176449-01 | 4-channel displacement monitor

Bently 3500/40M 176449-01 is a high-performance displacement monitor. The following is a detailed introduction to it:
1、 Product Overview
Bently 3500/40M 176449-01 is a 4-channel displacement monitor produced by Bently Nevada. It receives input from Bently Nevada displacement sensors, processes the signals to generate various vibration and displacement measurements, and compares the processed signals with user programmable alarm setpoints.
2、 Product Features
4-channel monitoring:
This monitor has 4 independent monitoring channels and can simultaneously monitor 4 different displacement or vibration points.
High precision measurement:
Advanced signal processing technology and high-precision sensors are used to achieve precise measurement of displacement and vibration.
Programmable alarm:
Users can program the alarm set points for each channel according to their actual needs. When the monitoring value exceeds the set value, the monitor will issue an alarm signal.
Easy to configure:
The 3500 framework configuration software can be used to configure each channel of the 3500/40M to have various functions such as radial vibration, axial displacement, differential expansion, and shaft eccentricity.
Multiple I/O module options:
Multiple I/O module options are provided, including TMR displacement I/O modules with internal terminals, external terminals, internal safety barriers and internal terminals, and external terminals, to meet the needs of different application scenarios.
3、 Product specifications and parameters
Brand: BENTLY
Model: 3500/40M 176449-01
Control principle: Other
Input signals: DC voltage, current
Input impedance: current impedance ≤ 160 Ω, voltage impedance ≥ 250K Ω
Input current/voltage: ≤ 30mA/≤ 7V
Output signals: 4-20mA, 0-10mA, 0-20mA, 1-5V, 0-5V
Output load: current type ≤ 500 Ω, voltage type ≥ 250K Ω
Communication protocol: MODBUS-RTU protocol, RS-485 transmission distance ≤ 1000 meters
Power supply: DC24V (± 10%), AC100-265V 50-60Hz
Power consumption: DC24V power consumption ≤ 1.5W, AC100-265V power consumption ≤ 2W
Insulation strength: 2500Vrms between input/output/power supply
Working temperature: 0~50 ℃
Relative humidity: ≤ 85% RH
Temperature drift: 50ppm
Installation method: 35mm DIN rail installation
Installation dimensions: 22.5 * 110 * 115mm (width * height * depth)
Measurement accuracy: 0.2% FS ± 1 word
Response time: ≤ 1S
4、 Application Fields
Bently 3500/40M 176449-01 is widely used for displacement and vibration monitoring of various large and medium-sized rotating machinery, such as steam turbines, compressors, fans, water pumps, etc. It is suitable for multiple industries such as steel, electricity, metallurgy, and chemical engineering, providing strong support for the stable operation and fault prevention of equipment.
