Bently 3500/22M 288055-01 is a monitoring and protection module produced by Bently Nevada Corporation. The following is a detailed introduction to it:
1、 Product Overview
The Bently 3500/22M 288055-01 module is mainly used for vibration monitoring and mechanical fault diagnosis of industrial equipment. Through high-precision vibration monitoring function, this module can monitor the vibration status of the equipment in real time, including parameters such as vibration speed, acceleration, and displacement, so as to timely discover potential faults and problems of the equipment, providing important reference information for equipment maintenance and upkeep.
2、 Main functions
Vibration monitoring: This module has high-precision vibration monitoring function, which can monitor the vibration situation of the equipment in real time, including key parameters such as vibration velocity, acceleration, and displacement.
Fault diagnosis: By collecting and analyzing vibration data, this module can identify and diagnose mechanical faults such as bearing wear, imbalance, looseness, etc., and promptly issue alarms or trigger maintenance operations.
Data Collection and Transmission: This module combines the functionality of the 3500/20 Rack Interface Module (RIM) with the data collection capabilities of communication processors (such as TDXnet) to continuously collect steady-state and transient dynamic (waveform) data, and transmit this data to the host software via an Ethernet link.
Remote monitoring and alarm: By communicating with devices such as the upper computer or PLC, this module can achieve remote monitoring and alarm functions. When there is an abnormality or malfunction in the equipment, the technical personnel can be notified in a timely manner for handling.
3、 Technical specifications
Brand: Bently
Specification: 3500/22M
Input voltage range: 12-48VDC
Output voltage range: 5VDC
Output current: maximum 10A
Size: 170mm x 105mm x 32mm
Weight: Approximately 120g
Operating temperature:- 20 ° C to+50 ° C
Storage temperature:- 40 ° C to+70 ° C
Environmental humidity: 5% to 95% relative humidity (no condensation)
CPU： 32-bit RISC processor
4、 Product Features
High reliability: This module has high reliability and stability, suitable for long-term operation in industrial environments, and can effectively monitor and protect the operating status of critical equipment.
Flexible configuration: Provides multiple configuration options that can be customized according to specific application needs, including input channel count, sampling rate, alarm settings, etc.
Rich communication interfaces: Supports multiple communication interfaces, such as Ethernet, for easy data exchange and integration with other monitoring or control systems.
Scalability: Supports modular design and can be combined with other Bently Nevada monitoring modules to build a more comprehensive monitoring system.
5、 Application Fields
The Bently 3500/22M 288055-01 module is widely used in various industrial fields, such as the power industry, oil and gas industry, chemical industry, and manufacturing industry. In the power industry, it can be used to monitor the vibration of generators, turbines, pumps, and fans; In the oil and gas industry, it can be used to monitor the vibration of compressors, pumps, and pipelines; In the chemical industry, it can be used to monitor the vibration of pumps, compressors, and mixers; In the manufacturing industry, it can be used to monitor the vibration of machine tools, robots, and conveyors.
In summary, the Bently 3500/22M 288055-01 module plays an important role in vibration monitoring and mechanical fault diagnosis of industrial equipment due to its high-precision vibration monitoring function, powerful fault diagnosis capability, flexible configuration options, and rich communication interfaces.
