The 3500 system now meets reliability requirements and can use the results of process failure analysis to better determine the required 3500 configuration. Various options include:
1. Standard system
2. Standard system with redundant power supply
3. TMR3500 framework with a single sensor input (TMRI/O: busbar system) and a single final stage component.
4. TMR3500 framework with a single sensor input (TMRI/O: bus system) and TMR final stage components.
5. TMR3500 framework with triple sensor inputs (TMRI/O: discrete) and single final stage components.
6. TMR3500 framework with triple sensor inputs (TMR1/O: discrete) and TMR final stage components.
To operate as a TMR system, the 3500 monitoring system must have the following modules installed:
● A TMR type framework interface module
Two power sources (if one is found to be faulty, the other can automatically supply all power without interruption).
● Two keyphasor modules in the same slot (if required for keyphasor signals).
● Two TMR relay modules in the same slot (if required)
Three monitor modules of the same type in adjacent slots.
2-3 communication channel modules in adjacent slots (if required for communication with peripherals).
3500 Monitoring System
The 3500 system is a fully functional monitoring system designed with the latest microprocessor technology. In addition to meeting the above needs, the 3500 system adds the following advantages:
-Enhanced operator information
-Increased integration with factory control computers
-Reduced installation and maintenance costs
-Improved reliability
-Enhanced operator information
The design of the 3500 system not only enhances operator information but also makes the display of information easy to understand. These features include:
-Enhanced Dataset
-Direct frequency amplitude
-Probe gap voltage
-1X amplitude and phase
-2X amplitude and phase
-Non 1X component amplitude
-Windows based operator display software
-Multi point display data
The 3500 system can provide the following three independent interfaces:
-Data management interface<external transient or dynamic data interface>
-Configuration/Data Port
-Communication gateway (supporting programmable logic controllers, process control computers, distributed control systems, and PC based control systems)
