Allen Bradley 1756-RM2 is a ControlLogix redundant module. The following is a detailed introduction to the module:
1、 Product Overview
The 1756-RM2 module aims to enhance the reliability and stability of industrial automation systems by providing redundant functionality. It is typically paired with ControlLogix controllers (such as the 1756-L7x series) in two chassis to achieve optimal scanning performance and controller redundancy.
2、 Main features
High performance:
1756-RM2 has enhanced features with speeds up to 1000 Mbps, providing powerful network support for industrial automation applications.
When paired with 1756-L7x controllers in two chassis, it provides optimal scanning performance.
Redundant functions:
This module enables controller redundancy by pairing with another 1756-RM2 from another ControlLogix chassis.
The use of redundant fiber optic ports ensures no single point of failure and improves the reliability of the system.
During channel switching, the processing chassis can maintain synchronization, but the scanning time may experience a delay of approximately 10 milliseconds.
Communication and Interface:
Supports up to 7 enhanced ControlNet and EtherNet/IP communication modules, facilitating system integration and data exchange.
In terms of wiring, it supports cables 1756-RMC1, 1756-RMC3, and 1756-RMC10, with lengths of 1m, 3m, and 10m respectively.
Compatibility and configuration:
Compatible with ControlLogix controllers 5560 and 5570, facilitating system integration and upgrades for users.
Use the redundant module configuration tool RSLinx 2.59 for configuration and management.
Electrical and physical characteristics:
The working voltage range is wide, with a current consumption of 1.16 A at 5.1V DC and 3.4 mA at 24V DC.
The maximum power consumption is 6W and the heat dissipation is 21 BTU/hour.
Moderate size, weighing 0.64 pounds (approximately 0.29 kilograms), with an open casing for easy installation and maintenance.
Safety and Diagnosis:
Enhanced security features through interference free diagnosis ensure stable operation of the system.
3、 Application scenarios
The 1756-RM2 redundant module is suitable for various application scenarios that require high reliability and stability in industrial automation and control systems. It is particularly suitable for critical systems that cannot tolerate single point of failure, such as petrochemical, power, metallurgical and other industries. In these applications, 1756-RM2 can provide reliable redundancy functions to ensure the continuous operation of the system and the integrity of data.
4、 Summary
Allen Bradley 1756-RM2 is a powerful and stable ControlLogix redundant module. It has the characteristics of high performance, redundant functions, multiple communication interfaces, and compatibility, which can meet the various needs of industrial automation and control systems. At the same time, the module also has excellent electrical and physical characteristics, as well as safety and diagnostic functions, providing users with reliable system assurance.
