ABB AI02J
Analog Input Module
Precision signal acquisition for industrial automation.
🔌 2-channel isolated analog input | High-speed conversion | Rugged design
⚙️ TECHNICAL SPECIFICATIONS
Core Parameters
|
Category
|
Specifications
|
|---|---|
|
Input Channels
|
2x isolated analog inputs
|
|
Signal Types
|
0–10 V, ±10 V, 0–20 mA, 4–20 mA (software-selectable)
|
|
Resolution
|
16-bit high-precision ADC
|
|
Sampling Rate
|
Up to 1 kHz per channel
|
|
Isolation
|
1500 V AC (channel-to-channel & channel-to-ground)
|
|
Accuracy
|
±0.1% FSR (Full Scale Range)
|
|
Operating Temp
|
-25°C to +70°C (-13°F to +158°F)
|
|
Power Supply
|
24 V DC (±15%)
|
|
Certifications
|
CE, UL, IEC 61000 (EMC), RoHS
|
🚀 FUNCTIONAL HIGHLIGHTS
1. Versatile Signal Handling
▸ Auto-ranging for voltage/current inputs (no hardware reconfiguration).
▸ Overload protection (up to 30 V DC/50 mA).
2. Seamless Integration
▸ ABB System 800xA compatibility for centralized control.
▸ PROFIBUS DP/V1 and Modbus RTU protocol support.
3. Advanced Diagnostics
▸ LED status indicators per channel (green=active, red=fault).
▸ Drift detection with automatic calibration alerts.
4. Industrial Robustness
▸ IP20 enclosure (mount in control cabinets or DIN rails).
▸ Vibration-resistant (up to 5g @ 10–150 Hz).
🔧 TYPICAL APPLICATIONS
|
Industry
|
Use Case
|
Key Benefit
|
|---|---|---|
|
Process Control
|
Tank level monitoring (4–20 mA sensors)
|
High accuracy in noisy environments
|
|
Energy
|
Solar inverter voltage/current feedback
|
Fast sampling for grid stability
|
|
Manufacturing
|
Temperature control via thermocouples (0–10 V)
|
Isolation prevents ground loops
|
|
Water Treatment
|
pH/conductivity measurement systems
|
Drift-free long-term reliability
|
📊 PERFORMANCE BENCHMARKS
|
Metric
|
Industry Standard
|
|
|---|---|---|
|
Resolution
|
16-bit
|
12-bit (typical)
|
|
Isolation Voltage
|
1500 V AC
|
500–1000 V AC
|
|
Sampling Rate
|
1 kHz/channel
|
100–500 Hz/channel
|
🛠️ INTEGRATION TIPS
- Wiring Best Practices
→ Use twisted-pair shielded cables for noise immunity.
→ Ground shields at one end only to avoid loops. - ABB Ecosystem Synergy
→ Pair with ABB CM5720 controller for real-time data processing.
→ Configure via ABB Automation Builder software. - Maintenance
→ Leverage predictive diagnostics to schedule calibration.
→ Replace filters in dusty environments every 12 months.
🌟 WHY CHOOSE AI02J?
- Dual-Channel Isolation: Measure two independent signals without interference.
- Future-Proof: Firmware-upgradable for evolving protocols (e.g., IoT-ready).
- Plug-and-Play: Pre-calibrated out of the box – reduces commissioning time by 40%.
📌 QUICK SUMMARY
|
Attribute
|
AI02J Advantage
|
|---|---|
|
Precision
|
16-bit ADC with ±0.1% accuracy
|
|
Flexibility
|
Supports 4 signal types per channel
|
|
Durability
|
Operates in extreme temps & vibrations
|
|
Compliance
|
Global certifications for hazardous areas
|
