ABB UFC933A101 3BHE048062R0101: Universal Field Controller
The ABB UFC933A101 3BHE048062R0101 is a versatile universal field controller designed for industrial automation, power generation, and motor control applications. As part of ABB’s Advant OCS (Open Control System) family, this controller integrates advanced process control logic, communication protocols, and diagnostic capabilities, making it ideal for complex automation tasks in demanding environments such as power plants, oil refineries, and manufacturing facilities.
Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Controller Type
|
Universal Field Controller (UFC)
|
|
Processor
|
32-bit RISC CPU with real-time operating system
|
|
Memory
|
16 MB RAM, 8 MB Flash (expandable via SD card)
|
|
I/O Capacity
|
Supports up to 512 digital/analog I/O points (modular expansion)
|
|
Communication Protocols
|
PROFIBUS DP, Modbus RTU/TCP, IEC 60870-5-104, OPC UA
|
|
Power Supply
|
24 V DC (±20%) or 100–240 V AC (±10%)
|
|
Operating Temperature
|
-25°C to +70°C
|
|
Protection Class
|
IP20 (panel-mounted)
|
|
Certifications
|
CE, UL, IEC 61131-2, RoHS
|
Key Features
1. Advanced Control Capabilities
- Multi-Domain Control: Supports PID control, sequence logic, and batch processing for diverse industrial processes.
- Redundancy: Dual power supply and communication ports for high availability.
- Real-Time Performance: Sub-millisecond response time for critical automation tasks.
2. Flexible I/O Integration
- Modular Design: Expandable with ABB S800 I/O modules for analog/digital signals, RTD, thermocouples, and HART communication.
- Signal Conditioning: Built-in isolation and surge protection (up to 2 kV) for noise immunity.
3. Industrial Communication
- PROFIBUS DP: Seamless integration with PLCs, HMIs, and SCADA systems.
- OPC UA Compliance: Enables secure data exchange for Industry 4.0 and IoT applications.
- Legacy Protocol Support: Modbus RTU/TCP for backward compatibility.
4. Diagnostics and Maintenance
- Self-Testing: Continuous monitoring of hardware, firmware, and communication health.
- Event Logging: Stores 10,000+ time-stamped alarms and events for root-cause analysis.
- Remote Access: Configure and troubleshoot via ABB Control Builder or web-based interfaces.
Applications
- Power Generation: Turbine control, excitation systems, and grid synchronization.
- Oil & Gas: Pipeline monitoring, compressor control, and safety shutdown systems.
- Water Treatment: Pump station automation, chemical dosing, and filtration processes.
- Manufacturing: Production line control, robotics, and quality assurance systems.
Advantages
- High Reliability: Designed for 24/7 operation with MTBF >150,000 hours.
- Scalability: Modular architecture supports system expansion without downtime.
- Cybersecurity: Role-based access control and encryption compliant with IEC 62443.
Keyword Summary
ABB UFC933A101, 3BHE048062R0101, universal field controller, Advant OCS, PROFIBUS DP, OPC UA, industrial automation, PID control, ABB S800 I/O, IEC 62443, redundant power supply, ABB Control Builder, real-time performance.
