ABB SM810K01 3BSE030928R1 Programmable Logic Controller (PLC) Module

ABB SM810K01 3BSE030928R1: Programmable Logic Controller (PLC) Module

The ABB SM810K01 3BSE030928R1 is a high-performance PLC I/O module designed for industrial automation, process control, and machine integration. Part of ABB’s AC 800M controller series, this module delivers robust signal processing, modular scalability, and seamless integration with ABB 800xA control systems for demanding applications in power generation, oil & gas, and manufacturing.

Technical Specifications

Category Details
Module Type Digital Input/Output (DI/DO) Module
Number of Channels 16 digital inputs / 16 digital outputs
Input Voltage 24 V DC (sink/source, configurable)
Output Voltage 24 V DC (transistor outputs, 0.5 A per channel)
Isolation Voltage 1500 V AC (channel-to-channel and channel-to-system)
Response Time Inputs: <1 ms | Outputs: <2 ms
Communication Interface PROFIBUS DP, IEC 61158-2, Ethernet/IP (via controller)
Power Consumption 3.5 W (typical)
Operating Temperature -25°C to +70°C
Humidity Tolerance 5–95% (non-condensing)
Certifications CE, UL 508, IEC 61131-2, RoHS

Core Features

1. High-Density I/O Configuration

• 16 Digital Inputs: Supports 24 V DC signals with configurable filtering (0.1–20 ms).
• 16 Digital Outputs: Transistor-based outputs with short-circuit and overload protection.
• LED Status Indicators: Per-channel diagnostics for input/output activity and faults.

2. Industrial-Grade Reliability

• Galvanic Isolation: 1500 V AC isolation ensures noise immunity and system safety.
• Surge Protection: Complies with IEC 61000-4-5 for voltage spikes up to 2 kV.
• Hot-Swappable Design: Replace modules without interrupting system operation.

3. Seamless Integration

• PROFIBUS DP Support: Direct connectivity to PLCs, HMIs, and SCADA systems.
• ABB 800xA Compatibility: Fully integrated with ABB’s distributed control system (DCS).
• Modular Expansion: Compatible with other AC 800M modules (e.g., analog I/O, communication).

4. Diagnostics & Maintenance

• Real-Time Fault Detection: Monitors open circuits, short circuits, and over-temperature.
• Event Logging: Stores 500+ timestamped events for root-cause analysis.
• Web-Based Configuration: Remote access via ABB’s Control Builder software.

Applications

• Power Plants: Turbine control, breaker management, and grid synchronization.
• Oil & Gas: Safety instrumented systems (SIS) and pipeline monitoring.
• Manufacturing: Production line automation, robotic control, and quality assurance.
• Water Treatment: Pump control, valve actuation, and chemical dosing.

Key Advantages

• High Speed: Sub-millisecond response time for critical automation tasks.
• Scalability: Expandable I/O capacity for future system upgrades.
• Global Compliance: Meets UL, IEC, and CE standards for industrial safety.
• Cybersecurity: Supports role-based access control (RBAC) and encrypted communication.
