ABB PP886H 3BSE069297R1 Communication Interface Module

$399.00

In stock

💥Name: Module/Controller/Touchpad/Driver/Load cell

Model: PP886H 3BSE069297R1

🚚Delivery time: goods in stock

3️⃣6️⃣5️⃣Warranty: 12 months

Shipping fee: Shipping fee: Please contact customer service.

📦Product packaging: The seller provides complete packaging

🌐Customs clearance fee: not included

☎️Phone/WeChat:15359021002

📧Email: LuckyXiao.909@Gmail.com

📲WhatsApp+86 15359021002

 🆔Skype:+86 15359021002

❤️Other websites: www.szcxgk.com

ABB PP886H 3BSE069297R1 Communication Interface Module

The ABB PP886H 3BSE069297R1 is a high-performance communication interface module designed for integration within ABB’s AC 800M distributed control system (DCS) and industrial automation platforms. It facilitates seamless data exchange between controllers, field devices, and enterprise-level systems, ensuring reliable communication in mission-critical industrial environments. Below is a detailed breakdown of its features, technical specifications, and applications.


1. Key Features

  • Multi-Protocol Support:
    • Profinet IO (Class 1 and Class 3) for high-speed industrial Ethernet communication.
    • Backward compatibility with legacy protocols via optional modules (e.g., Profibus DP, Modbus TCP).
  • Redundancy and Reliability:
    • Dual-channel redundancy for uninterrupted network operation.
    • Hot-swappable design minimizes downtime during maintenance or upgrades.
  • Scalability:
    • Supports up to 256 Profinet IO devices per module, ideal for large-scale automation networks.
    • Expandable via additional communication modules for hybrid architectures.
  • Robust Industrial Design:
    • Operating Temperature: -25°C to +70°C (-13°F to +158°F).
    • EMC Compliance: Meets IEC 61326 and IEC 61000-6-2/4 standards for electromagnetic compatibility.
    • IP20 protection against dust and limited moisture ingress.
  • Diagnostics and Monitoring:
    • Real-time network health monitoring with integrated LEDs (power, activity, fault status).
    • Advanced diagnostics via ABB’s Control Builder M engineering tool.

2. Technical Specifications

Parameter
Details
Part Number
Module Type
Profinet IO Controller/Communication Interface
Protocols Supported
Profinet IO (RT/IRT), optional Profibus DP via add-on modules
Data Transfer Rate
Up to 100 Mbps (Ethernet)
Number of Devices
Up to 256 Profinet IO devices per module
Power Supply
24 VDC (±10%), redundant input support
Isolation Voltage
1500 V (between communication channels and power supply)
Certifications
CE, UL, RoHS, ATEX (for hazardous areas)
Dimensions
Standard AC 800M module size (approx. 200 x 50 x 150 mm)

3. Functional Capabilities

  • Profinet IO Control:
    • Acts as a Profinet IO Controller, managing real-time data exchange with field devices (e.g., sensors, drives, I/O modules).
    • Supports Isochronous Real-Time (IRT) communication for time-critical applications.
  • Legacy Protocol Integration:
    • Optional Profibus DP or Modbus TCP integration via expansion modules.
  • Network Management:
    • Configures and monitors Profinet network topology, device status, and cycle times.
    • Automatic device replacement without reconfiguration (Profinet device replacement).
  • Cybersecurity:
    • Supports Profinet Security (optional) for encrypted communication and access control.

4. Applications

  • Automotive Manufacturing: Real-time control of robotic assembly lines and conveyor systems.
  • Power Generation: Integration of turbine control systems with field devices via Profinet.
  • Oil & Gas: Offshore platform automation and pipeline monitoring.
  • Water Treatment: Distributed I/O management in pump stations and filtration plants.
  • Pharmaceuticals: Batch process control with strict timing requirements.

5. Integration with ABB Systems

  • AC 800M Controllers: Direct compatibility for centralized automation control.
  • S800 I/O Series: Integrates with remote I/O modules for scalable system expansion.
  • Industrial IT 800xA: Centralized monitoring via ABB’s DCS platform.

6. Advantages

  • High-Speed Communication: Optimized for low-latency data exchange in Industry 4.0 applications.
  • Flexibility: Supports hybrid networks combining Profinet and legacy protocols.
  • Fault Tolerance: Redundant network paths and hot-swappability enhance system uptime.
  • Ease of Use: Plug-and-play configuration with GSDML files for third-party device integration.

7. Software and Configuration

  • Control Builder M: ABB’s engineering suite for configuring communication parameters, mapping I/O data, and testing network performance.
  • TIA Portal (Siemens): Optional integration for mixed-vendor environments.
  • 800xA Operator Workplace: Provides HMI visualization and diagnostics.

8. Ordering and Compatibility

  • Replacement Part: Use part number 3BSE069297R1 for direct replacement in existing AC 800M systems.
  • Compatible Controllers: Pairs with AC 800M CPUs (e.g., PM865, PM867).

9. Summary

The ABB PP886H 3BSE069297R1 is a cutting-edge communication interface module designed for modern industrial networks, combining high-speed Profinet IO support with backward compatibility for legacy systems. Its robust design, scalability, and redundancy features make it ideal for applications requiring precise, real-time control in demanding environments.
