ABB PFTL101A 1.0KN 3BSE004166R1 – Pressure Transmitter
The ABB PFTL101A 1.0KN 3BSE004166R1 is a high-precision pressure transmitter designed for industrial process measurement and control. It provides accurate and reliable pressure monitoring in demanding environments, supporting applications in oil and gas, water treatment, chemical processing, and HVAC systems.
Technical Parameters
|
Category
|
Specification
|
|---|---|
|
Measurement Range
|
0–1.0 kN (kilonewton) or customizable ranges
|
|
Output Signal
|
4–20 mA analog (2-wire), HART protocol compatibility
|
|
Power Supply
|
12–30 V DC (loop-powered)
|
|
Accuracy
|
±0.1% of full scale (typical)
|
|
Long-Term Stability
|
±0.1% of URL (upper range limit) per year
|
|
Process Connection
|
G1/2″ or NPT 1/2″ threaded, stainless steel (AISI 316L)
|
|
Pressure Medium
|
Compatible with liquids, gases, and steam (non-corrosive)
|
|
Operating Temperature
|
-40°C to +125°C (process temperature)
-20°C to +85°C (ambient temperature) |
|
Protection Class
|
IP66/68 (submersible and dust-tight)
|
|
Certifications
|
SIL 2 (IEC 61508/61511), ATEX, IECEx, CE, RoHS
|
Functional Features
- High Accuracy & Stability
- Utilizes advanced sensor technology (e.g., piezoresistive or capacitive sensing) for precise pressure measurement.
- Temperature-compensated to minimize drift in extreme conditions.
- Robust Construction
- Stainless steel housing and diaphragm for corrosion resistance.
- Hermetically sealed electronics for protection against moisture and dust.
- Versatile Communication
- HART Protocol: Enables digital configuration, diagnostics, and remote calibration via HART communicators.
- Optional PROFIBUS PA/FF or Modbus interfaces for integration with industrial automation systems.
- Diagnostics & Safety
- Self-monitoring for sensor health, cable breaks, and overpressure conditions.
- SIL 2 certification for safety-critical applications (e.g., chemical plants).
- Easy Installation & Maintenance
- Zero and span adjustment via local push buttons or HART tools.
- Modular design allows quick replacement of components.
- Wide Application Suitability
- Ideal for hydrostatic level measurement, pump control, and filter monitoring.
- Compatible with aggressive media when paired with ceramic or Hastelloy sensors (optional).
- Environmental Resilience
- Operates reliably in high-vibration, high-humidity, and explosive atmospheres (ATEX/IECEx certified).
Typical Applications
- Oil & Gas: Pipeline pressure monitoring, wellhead control.
- Water/Wastewater: Pump protection, tank level measurement.
- Chemical Processing: Reactor pressure control, leak detection.
- HVAC: Chiller and boiler system pressure regulation.
Compliance & Standards
- Safety: ATEX II 1/2G Ex ia IIC T6, IECEx, SIL 2.
- Environmental: IP66/68, NEMA 4X.
- Quality: IEC 60770, EN 61298.
Conclusion
The ABB PFTL101A 1.0KN 3BSE004166R1 is a versatile and rugged pressure transmitter engineered for precision and reliability in industrial automation. Its combination of high accuracy, robust construction, and compliance with global safety standards makes it a trusted solution for critical pressure measurement tasks. Designed for ease of integration and maintenance, it ensures long-term performance in harsh and hazardous environments, aligning with ABB’s commitment to advanced process instrumentation.
