ABB PCD230A101 3BHE022291R0101 – Technical Specifications, Functions, and Applications
Technical Parameters
|
Parameter
|
Specification
|
|---|---|
|
Device Type
|
Multifunctional Protection Relay (Part of ABB’s Relion® 600 Series).
|
|
Rated Voltage
|
24–250 VDC / 100–240 VAC (operational range).
|
|
Frequency Range
|
45–65 Hz, adaptable to global power systems.
|
|
Protection Functions
|
Overcurrent, earth fault, frequency protection, motor/generator protection.
|
|
Communication Interfaces
|
• IEC 61850
• Modbus RTU/TCP • Ethernet TCP/IP • RS-485 serial port. |
|
Operating Temperature
|
-25°C to +70°C (-13°F to +158°F).
|
|
Enclosure Rating
|
IP40 (dust and limited moisture protection).
|
|
Certifications
|
Complies with IEC 60255, IEC 61850, UL, CE, and global grid standards.
|
|
Display & Interface
|
LCD screen with intuitive menu navigation for configuration and diagnostics.
|
|
Mechanical Durability
|
Designed for >10 years of reliable operation in harsh industrial environments.
|
Key Functions
- Comprehensive Protection
- Advanced algorithms for overcurrent, undervoltage, overvoltage, and frequency protection, safeguarding electrical equipment from faults.
- Motor/Generator Protection
- Specialized functions like stall prevention, thermal overload, and phase unbalance protection for motors and generators.
- Real-Time Monitoring
- Continuous measurement of voltage, current, power, and harmonics for system health analysis.
- Event Logging
- Stores fault records, oscillography data, and timestamps for post-event analysis.
- Communication & Integration
- Supports IEC 61850 for seamless integration with substation automation systems (SAS) and SCADA.
- User-Friendly Configuration
- Local or remote setup via ABB’s PCM600 software, enabling easy customization of protection settings.
Application Fields
- Power Generation
- Protection of generators, turbines, and renewable energy systems (wind/solar farms).
- Industrial Plants
- Motor control centers (MCCs), pump systems, and critical machinery in manufacturing.
- Substations
- Feeder protection, transformer monitoring, and grid stability management.
- Infrastructure
- Water treatment facilities, data centers, and hospital power backup systems.
- Transportation
- Rail electrification and port infrastructure power distribution.
Why Choose Us?
- In-Stock Availability: Guaranteed immediate dispatch from our global warehouse.
- Fast Shipping: Orders processed within 24 hours for urgent project deadlines.
- 1-Year Warranty: Full coverage against defects, ensuring confidence in product quality.
The ABB PCD230A101 3BHE022291R0101 protection relay is a versatile solution for modern electrical networks, combining robust protection, precise monitoring, and seamless communication. Its compliance with international standards and adaptability to diverse applications make it indispensable for industries prioritizing reliability and safety. Contact us today for expert support and competitive pricing!
