ABB LD800HSEEX 3BSE073314R1 – Technical Specifications, Functions, and Applications
Technical Parameters
|
Parameter
|
Specification
|
|---|---|
|
Device Type
|
High-performance industrial drive (AC drive/VFD).
|
|
Power Range
|
Designed for motors up to 0.75–800 kW (specific range depends on model).
|
|
Input Voltage
|
380–500 V AC, 3-phase, 50/60 Hz.
|
|
Output Voltage
|
0–100% of input voltage, adjustable for precise motor control.
|
|
Control Method
|
Sensorless vector control (SVC) and flux vector control (FVC).
|
|
Communication Interfaces
|
• PROFIBUS DP
• Modbus RTU/TCP • Ethernet/IP • Built-in I/O terminals. |
|
Protection Features
|
Overcurrent, overvoltage, undervoltage, short-circuit, and thermal overload protection.
|
|
Operating Temperature
|
-10°C to +50°C (derating required above +40°C).
|
|
Enclosure Rating
|
IP21 (standard) or higher with optional filters.
|
|
Certifications
|
CE, UL, cUL, and compliant with IEC 61800 standards.
|
Key Functions
- Advanced Motor Control
- Delivers smooth torque and speed regulation for induction and permanent magnet motors, enhancing energy efficiency.
- Energy Optimization
- Built-in energy-saving algorithms reduce power consumption in variable load applications (e.g., pumps, fans).
- Dynamic Braking
- Supports regenerative braking and DC bus sharing for applications requiring rapid deceleration.
- User-Friendly Interface
- LCD keypad with multilingual menus for easy parameter configuration, diagnostics, and real-time monitoring.
- Application Macros
- Pre-programmed settings for common applications (e.g., pump control, conveyor systems) to simplify setup.
- Safety Integration
- Supports STO (Safe Torque Off) and other safety protocols compliant with SIL 2/3 standards.
Application Fields
- Water and Wastewater Treatment
- Pump and blower control for energy-efficient flow regulation.
- HVAC Systems
- Fan and compressor speed control in heating, ventilation, and air conditioning units.
- Manufacturing
- Conveyor belts, extruders, and CNC machinery requiring precise motion control.
- Mining and Minerals
- Crushers, conveyors, and hoists in harsh industrial environments.
- Renewable Energy
- Integration with solar/wind power systems for grid stability and motor control.
Why Choose Us?
- In-Stock Availability: Ready for immediate dispatch from our global warehouse.
- Fast Shipping: Guaranteed delivery within 1–3 business days (region-dependent).
- 1-Year Warranty: Full coverage against manufacturing defects, ensuring reliability and customer satisfaction.
The ABB LD800HSEEX 3BSE073314R1 variable frequency drive (VFD) combines robust performance with intelligent control, making it ideal for industries demanding precision, energy efficiency, and operational flexibility. Its compliance with global standards and adaptability to diverse applications ensures seamless integration into modern automation systems. Contact us today for competitive pricing and technical support!
