ABB GFD563A101 3BHE046836R0101
Premium Industrial Protection Relay for Power Systems
Technical Parameters:
- Input Voltage: 24-48 V DC / 85-265 V AC (wide range)
- Frequency Range: 45-65 Hz (adjustable for global compatibility)
- Accuracy: ±0.5% for voltage/current measurements (IEC 60255-24 compliant)
- Relay Outputs: 6x configurable NO/NC contacts (5 A @ 250 V AC)
- Communication: Ethernet, RS-485 (Modbus RTU/TCP), IEC 61850 protocol support
- Operating Temp: -40°C to +85°C (suitable for harsh environments)
- Certifications: UL, CE, IEC 60255, RoHS
Key Features:
- Multi-Function Protection: Overcurrent, undervoltage, earth fault, and frequency protection.
- Advanced Monitoring: Real-time data logging, event recording (up to 1,000 events), and waveform capture.
- Plug-and-Play Design: DIN-rail mounting, intuitive HMI with 128×64 LCD for quick setup.
- Cybersecurity Ready: Password protection and role-based access control.
- ABB Ecosystem Integration: Compatible with ABB Relion® series and PCM600 configuration tools.
Advantage:
✅ High ROI: Reduces downtime with <20 ms fault detection and isolation.
✅ Versatile Use: Ideal for substations, renewable energy systems, and industrial grids.
✅ Global Compliance: Meets IEEE and IEC standards for cross-border projects.
✅ Low Maintenance: 10+ year lifespan with self-test diagnostics.
