ABB GFD233A 3BHE022294R0103 Communication Interface Module

$399.00

In stock

💥Name: Module/Controller/Touchpad/Driver/Load cell

Model: GFD233A 3BHE022294R0103

🚚Delivery time: goods in stock

3️⃣6️⃣5️⃣Warranty: 12 months

Shipping fee: Shipping fee: Please contact customer service.

📦Product packaging: The seller provides complete packaging

🌐Customs clearance fee: not included

☎️Phone/WeChat:15359021002

📧Email: LuckyXiao.909@Gmail.com

📲WhatsApp+86 15359021002

 🆔Skype:+86 15359021002

❤️Other websites: www.szcxgk.com

ABB GFD233A 3BHE022294R0103 Communication Interface Module

The ABB GFD233A 3BHE022294R0103 is a specialized communication interface module designed for integration within ABB’s industrial automation systems, particularly in distributed control systems (DCS) and process automation applications. This module facilitates reliable data exchange between controllers, field devices, and higher-level systems, ensuring seamless operation in industries such as power generation, oil and gas, chemical processing, and water treatment. Below is a detailed breakdown of its features, technical specifications, and industrial applications.


1. Key Features

  • Multi-Protocol Support:
    • Enables communication via Profibus DPModbus TCP/RTU, and OPC UA protocols, ensuring compatibility with diverse industrial devices and systems.
    • Acts as a gateway between field devices and control systems for real-time data integration.
  • High Reliability:
    • Redundant communication channels to ensure continuous operation in mission-critical environments.
    • Hot-swappable design allows module replacement without system shutdown, minimizing downtime.
  • Robust Construction:
    • Industrial-grade enclosure with IP20 protection, suitable for harsh environments with dust and limited moisture exposure.
    • Wide operating temperature range (-25°C to +70°C / -13°F to +158°F) for deployment in extreme conditions.
  • Diagnostics and Monitoring:
    • Integrated LEDs for real-time status indication (power, activity, faults).
    • Advanced diagnostics for network health monitoring and error logging.

2. Technical Specifications

Parameter Details
Part Number 3BHE022294R0103
Module Type Communication Interface/Gateway
Supported Protocols Profibus DP, Modbus RTU/TCP, OPC UA
Data Transfer Rate Up to 12 Mbps (Profibus DP), 10/100 Mbps (Ethernet)
Power Supply 24 VDC (±10%), redundant input support
Isolation Voltage 1500 V (between communication channels and power supply)
Certifications CE, UL, RoHS, IEC 61131-2 (EMC compliance)
Dimensions Standard modular size (approx. 120 x 40 x 150 mm)

3. Functional Capabilities

  • Protocol Conversion:
    • Translates data between fieldbus protocols (e.g., Profibus DP) and Ethernet-based systems (e.g., Modbus TCP), enabling interoperability in hybrid networks.
  • Data Aggregation:
    • Collects and routes data from multiple field devices (sensors, actuators, I/O modules) to central controllers or SCADA systems.
  • Redundancy Management:
    • Supports dual-network configurations for fault-tolerant communication in critical processes.
  • Integration with ABB Systems:
    • Compatible with ABB’s AC 800M controllers and S800 I/O series, forming part of the Industrial IT 800xA ecosystem.

4. Applications

  • Power Plants: Integration of turbine control systems with field devices via Profibus DP.
  • Oil & Gas: Real-time data exchange between offshore platform sensors and central DCS.
  • Chemical Processing: Bridging legacy Modbus RTU devices with modern OPC UA-enabled systems.
  • Water Treatment: Monitoring and control of distributed I/O modules in pump stations.

5. Advantages

  • Interoperability: Bridges legacy and modern industrial networks, extending the lifespan of existing infrastructure.
  • High Availability: Redundant communication paths and hot-swap capability ensure minimal downtime.
  • Ease of Configuration: Simple setup via ABB’s Control Builder M engineering tool.
  • Scalability: Modular design supports expansion with additional communication modules.

6. Software and Configuration Tools

  • Control Builder M: ABB’s engineering suite for configuring communication parameters, mapping data points, and testing network performance.
  • 800xA System: Centralized platform for monitoring network status and diagnostics.

7. Ordering and Compatibility

  • Replacement Part: Use part number 3BHE022294R0103 for direct compatibility with existing ABB systems.
  • Compatible Systems: Integrates with ABB’s AC 800M controllers, CI854 communication modules, and third-party PLCs/SCADA systems.

8. Summary

The ABB GFD233A 3BHE022294R0103 is a versatile communication interface module designed to enhance connectivity in industrial automation networks. Its robust design, multi-protocol support, and redundancy features make it ideal for critical applications requiring reliable and scalable data exchange.
