ABB CI867K01 3BSE043660R1 is a powerful intelligent I/O module, which also belongs to the communication module. The following is a detailed introduction of the module:
1、 Basic Information
Brand: ABB
Model: CI867K01
Part number: 3BSE043660R1
2、 Technical features
High performance processor: This module is equipped with a built-in high-performance processor, which significantly enhances data processing and communication capabilities, and can meet the real-time and high-performance requirements of industrial automation systems.
Multiple communication protocol support: Supports multiple communication protocols such as Modbus TCP, PROFIBUS DP, EtherNet/IP, etc., enabling seamless connection and data exchange with other industrial devices, providing great flexibility and compatibility.
Independent data processing and control logic: With independent data processing capabilities and control logic, it significantly enhances the control function of the system.
Redundancy technology: supports redundant configuration, and can add redundant components (such as redundant processors, central servers, and transmission media) to critical parts to improve system reliability and stability.
Intelligent control algorithm: Adopting advanced control algorithms such as fuzzy logic, expert systems, genetic algorithms, neural networks, etc., it forms control modules and network systems with artificial intelligence, improving the control level of the system.
Artificial intelligence technology: Utilizing artificial intelligence technology for self diagnosis and early prediction of faults, optimizing process control.
Lightning protection and overcurrent protection: With 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions, the module ensures stable operation in industrial environments.
3、 Physical and electrical parameters
Size: There are two ways to describe the length, which are 127.5mm or 170mm; There are two ways to describe the width, which are 59mm or 105mm; There are two versions of height, which are 185mm or 32mm.
Weight: There are two versions, which are 0.62kg or approximately 120g.
Environmental requirements: The operating temperature is -20 ° C to+50 ° C (also known as -40 ° C to+70 ° C), the storage temperature is -40 ° C to+70 ° C, and the environmental humidity is 5% to 95% relative humidity (no condensation).
Power supply voltage: 12-48VDC (also known as 24V DC).
Output voltage: 5VDC.
Power consumption: The typical value is 160 mA.
Connector type: RJ-45 female head (8-pin), 9-pin Sub-D socket connector (for Profibus DP).
Communication rate: It has multiple communication rate options, such as 9.6kBit/s, 19.2 kBit/s, 45.45kBit/s, etc., with a maximum of 12MBit/s (the specific rate depends on the communication protocol and configuration used).
4、 Application Fields
The CI867K01 module belongs to the ABB industrial automation control module series, mainly used to achieve communication and data exchange with other industrial equipment. It is suitable for multiple fields such as electricity, petroleum, and mining, especially in situations that require high performance, high reliability, and complex control. This module can serve as a core component for system control and communication, working in conjunction with other devices and systems to achieve monitoring, control, and management of automated production lines.
