ABB AO2000-LS25 is a high-precision laser analyzer. The following is a detailed introduction to it:
1、 Application Fields
The ABB AO2000-LS25 laser analyzer is widely used in multiple fields, including industrial process control, environmental monitoring, mineral exploration, metal alloy analysis, food and beverage production, and life sciences. It supports real-time analysis and remote sensing monitoring of multiple chemical components, providing strong technical support for these fields.
2、 Measurement principle
This analyzer is based on Tunable Diode Laser Absorption Spectroscopy (TDLAS) technology and uses an emitter/receiver configuration to measure the average gas concentration along the line of sight path. The measurement principle is infrared single line absorption spectroscopy, which means that each gas has different absorption lines at specific wavelengths. By scanning the selected gas absorption line with laser wavelength and detecting changes in light intensity, the concentration of the target gas can be calculated. In order to improve sensitivity, the analyzer also uses wavelength modulation technology.
3、 Instrument composition
The ABB AO2000-LS25 laser analyzer consists of three independent units:
Transmitter unit with purification function: including laser module, temperature stable diode laser, collimating optical lens group, and main electronic equipment, installed in a coated aluminum box.
Receiving unit with purification function: includes a focusing lens, photodetector, and receiver electronic components, housed in a coated aluminum box.
Power supply device: provides the necessary power for the transmitter and receiver.
4、 Features and Functions
High precision: Advanced laser and electronic technology are used to ensure the accuracy and reliability of measurement results.
Real time monitoring: It can continuously monitor the gas concentration in chimneys, pipelines, process rooms and other places on site, providing timely data support.
Easy to install and maintain: The installation and maintenance of the instrument is relatively simple, but it requires careful attention and preparation to avoid damaging the instrument and rendering the warranty invalid.
Multiple communication methods: The optional Ethernet board provides TCP/IP communication through a local area network (LAN) instead of serial communication. Meanwhile, the RS-232 port can be used for direct serial communication with a PC.
5、 Application scenarios
Industrial process control: used for real-time monitoring and analysis of chemical composition in production processes in industrial fields such as chemical, petrochemical, and pharmaceutical industries.
Environmental monitoring: used for detecting pollutants in the atmosphere, water bodies, and soil to support environmental protection and monitoring.
Mining and geological exploration: used to analyze elements in soil, rocks, and ores to support mineral exploration and mining.
Metal and alloy analysis: used in metal production and quality inspection to detect the composition and impurities in alloys.
Food and beverage production: used to analyze the ingredients in food to ensure product quality and compliance.
Life science and medical research: used for the analysis of biological samples, such as cells, tissues, and biomolecules.
