ABB 87TS01L-E/R1313 GJR2368900R1313: Motor Protection Relay
The ABB 87TS01L-E/R1313 GJR2368900R1313 is a multi-functional motor protection relay designed for industrial motors, pumps, compressors, and HVAC systems. Part of ABB’s Relion® protection series, this relay integrates advanced motor protection algorithms, communication protocols, and diagnostic tools to ensure safe and efficient operation of motors in demanding environments.
Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Rated Voltage
|
24–250 V DC / 100–240 V AC (±20%)
|
|
Current Inputs
|
1 A / 5 A (configurable), ±1% accuracy
|
|
Protection Functions
|
Overload, phase loss, short-circuit, earth fault, thermal overload, under/over-voltage, motor stall, jam detection
|
|
Communication Protocols
|
Modbus RTU, Modbus TCP/IP, PROFIBUS DP, IEC 61850 (optional)
|
|
I/O Configuration
|
8 digital inputs, 6 relay outputs, 2 analog outputs
|
|
Operating Temperature
|
-25°C to +70°C
|
|
Certifications
|
UL 508, CE, IEC 60255, RoHS
|
|
Enclosure Rating
|
IP20 (panel-mounted)
|
Key Features
1. Comprehensive Motor Protection
- Thermal Model: IEC 60255-8 compliant thermal overload protection with customizable curves.
- Stall/Jam Detection: Prevents motor damage during mechanical blockages or prolonged start-up.
- Phase Imbalance: Detects and trips on phase asymmetry or loss (adjustable threshold).
2. Advanced Monitoring & Diagnostics
- Real-Time Data: Measures voltage, current, power, energy, and power factor.
- Event Logging: Stores 1,000+ time-stamped events (trips, alarms, parameter changes).
- Waveform Capture: Records fault waveforms for post-event analysis.
3. Industrial Communication
- Modbus RTU/TCP: Seamless integration with PLCs, HMIs, and SCADA systems.
- PROFIBUS DP Support: Ideal for Siemens automation environments.
- IEC 61850 Compatibility: Future-ready for smart grid and digital substations.
4. User-Friendly Interface
- LCD Display: 4-line backlit display for real-time monitoring and settings.
- Local Control: Manual start/stop and reset functions via front panel.
- Configuration Software: Programmable via ABB PCM600 or Relay Configuration Suite.
Applications
- Industrial Motors: Protection of pumps, fans, conveyors, and crushers.
- Oil & Gas: Motor control in hazardous areas (ATEX/IECEx certified versions available).
- Water Treatment: Pump protection and energy management in municipal systems.
- Building Automation: HVAC motor control for commercial complexes.
Why Choose ABB 87TS01L-E/R1313 GJR2368900R1313?
- High Accuracy: ±1% measurement accuracy for precise motor control.
- Modular Design: Expandable I/O and firmware updates for evolving needs.
- Global Compliance: Meets UL, CE, and IEC standards for worldwide deployment.
