ABB 3BHL000986P8110
━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Industrial Automation Guardian | Precision & Durability
🔍 Core Identity
Device Type: High-Performance Motor Protection Relay
Mission: Safeguard motors and drives from electrical faults, ensuring seamless operations in harsh industrial environments.
📊 Technical Blueprint
|
Attribute
|
Specifications
|
|---|---|
|
Rated Current
|
0.1–100 A (Adjustable via CT Ratio)
|
|
Voltage Range
|
24–250 VDC / 100–240 VAC (50/60 Hz)
|
|
Protection Functions
|
Overload, Phase Loss, Short-Circuit, Ground Fault
|
|
Communication
|
Modbus RTU, PROFIBUS DP, Ethernet/IP
|
|
Operating Temp
|
-40°C to +85°C (Extreme Environment Ready)
|
|
Enclosure Rating
|
IP65 (Dustproof & Water-Resistant)
|
|
Certifications
|
UL, CE, IEC 60947, ATEX
|
🚀 Key Features
🛡️ Advanced Protection
- Thermal Overload Modeling: Mimics motor heating/cooling curves for precise tripping.
- Asymmetry Detection: Flags phase imbalance or voltage dips to prevent motor burnout.
📡 Smart Connectivity
- Real-Time Diagnostics: Tracks motor health metrics (current, temp, vibration) via Modbus.
- Cybersecurity: Encrypted communication and role-based access control.
💡 User-Centric Design
- OLED Touchscreen: Intuitive menu for parameter adjustments and fault history.
- Plug-in Modules: Add I/O cards (e.g., analog inputs, relay outputs) in seconds.
🌱 Sustainability Edge
- Energy Efficiency Reports: Logs motor energy use to optimize consumption.
- RoHS Compliance: Lead-free, recyclable materials.
🌍 Application Scenarios
🏭 Heavy Industry
- Mining: Conveyor belt motors, crushers.
- Cement: Kiln drives, ball mill motors.
⚡ Energy & Utilities
- Pump Stations: Water treatment, oil pipelines.
- Wind Turbines: Gearbox motor protection.
🚢 Marine & Offshore
- Shipboard Motors: HVAC, winches (ATEX certified).
🏗️ Manufacturing
- Robotics: Joint actuators, CNC spindle motors.
🌟 Why 3BHL000986P8110?
- Mission-Critical Reliability: SIL 2 certified for safety systems.
- Future-Ready: Firmware upgradable for IoT integration.
- Global Compliance: ATEX/IECEx for explosive zones.
🚚 Stock & Support
🔹 Immediate Availability: Ships within 24 hours from global hubs.
🔹 1-Year Warranty: Full defect coverage + lifetime technical support.
🔹 Custom Configurations: Pre-programmed settings for your motor specs.
━━━━━━━━━━━━━━━━━━━━━━━━
Power resilience starts here. Contact us for bulk orders or urgent needs! 📞+8615359021002
