ABB 1TGE120021R0010 Protection relay module
The Guardian of Grid Stability & Precision
◈ Core Identity
The ABB 1TGE120021R0010 is a protective relay module engineered for high-voltage power transmission and distribution systems. Designed to safeguard electrical grids against faults, overloads, and asymmetrical conditions, it combines ultra-fast tripping logic with adaptive protection algorithms, ensuring grid resilience in utilities, renewable energy farms, and industrial microgrids.
◼ Technical Architecture
- Processing: Dual-core 32-bit DSP + FPGA co-processor, executing 15,000 cycles/sec for real-time waveform analysis.
- Input/Output: 12 analog inputs (1A/5A CT, 110V VT), 16 programmable digital I/O, 4 high-speed relay outputs (5A @ 250V AC).
- Communication: IEC 61850-9-2 LE Sampled Values, DNP3 over TCP/IP, and Modbus RTU for legacy system integration.
- Ruggedness: Operates at -40°C to +85°C, withstands 15kV surge immunity (ANSI C37.90), and 95% humidity non-condensing.
◆ Innovation at its Core
1. Phasor Measurement Unit (PMU) Integration
Synchrophasor data streaming at 120 samples/sec enables wide-area grid monitoring, aligning with IEEE C37.118 standards for smart grid compliance.
2. AI-Driven Fault Classification
Neural network algorithms distinguish between arc flash, ground faults, and transient disturbances with 99.7% accuracy, minimizing false tripping.
3. Green Grid Optimization
Dynamic load-shedding algorithms prioritize renewable energy sources during peak demand, reducing carbon footprint by 12-18%.
◗ Application Scenarios
|
Sector
|
Critical Role
|
Performance Leap
|
|---|---|---|
|
Offshore Wind Farms
|
Anti-islanding protection
|
<8ms fault clearance
|
|
Data Center Power
|
N+1 redundancy coordination
|
0.1ms sync precision for STS
|
|
Urban Metro Grids
|
Harmonic filtering & voltage sag mitigation
|
THiD reduction to <1.5%
|
◉ User-Centric Features
- Touchscreen HMI: 7-inch capacitive display with drag-and-drop logic editor.
- Cybersecurity Suite: Role-based access control, IEC 62351-compliant encryption, and tamper-evident seals.
- Cloud-Ready Diagnostics: Direct data export to ABB Ability™ Asset Health Center for predictive analytics.
◼ Compliance & Longevity
Certified for IEC 60255, IEEE C37.90, and KEMA COC (Netherlands). Backward-compatible with electromechanical relays via analog input modules. 20-year lifecycle support with firmware update guarantees.
◈ Global Availability & Logistics
📦 Stock Status: 🟢 1000+ UNITS AVAILABLE – Ships same-day from hubs in 🇺🇸 New Jersey, 🇸🇪 Ludvika, 🇦🇪 Dubai, and 🇨🇳 Beijing.
🚚 Logistics Options:
- Express: DHL/FedEx Priority (1-3 days, door-to-door tracking)
- Project Cargo: Incoterms FOB/CIF for bulk orders
- Hazardous Certified: IEC 60255-compliant packaging for air/sea
🔧 Warranty: ✅ 1-Year Full Coverage + optional 10-year extended service plans.
🌐 Contact Us:
📧 Email: luckyxiao.909@gmail.com
📱 WhatsApp: +86 15359021002
☎️ Phone/WeChat: 15359021002
Final Note
The 1TGE120021R0010 isn’t just a relay—it’s a grid sentinel for the decarbonized era. By fusing ultrafast protection with AI-driven grid intelligence, ABB empowers utilities to balance reliability, sustainability, and digital transformation.
⚡ Order Today:
MOQ: 1 unit (volume discounts negotiable)
Lead Time: 24hrs for standard orders • Custom configuration files pre-loaded upon request.
